Josi CE installation and operations manual

This manual describes how to install the Josi CE Community Preview from this repository. It is intentionally explicit. Commands are written for a Linux server unless a section says otherwise.

Release warning

Josi CE 0.1 is still under construction. Phase 9 is incomplete and Phases 10 through 12 are not implemented at the time this paragraph was written. In particular, the product does not yet provide its promised backup, restore, update, rollback, diagnostics, or identity/memory workflows. Do not treat this preview as production-ready merely because the containers start.

1. What the standard installation creates

The default Compose deployment creates five service roles:

Two optional services are disabled unless explicitly selected:

The database is attached only to the private data network. Caddy is attached only to the edge network. The worker is not reachable through the proxy.

2. Supported deployment shapes

Choose one deployment shape before changing configuration.

2.1 Public HTTPS with bundled Caddy

Use this for the usual single-server installation. You need a public DNS name, inbound TCP ports 80 and 443, and no other process already using those ports. Caddy obtains and renews the TLS certificate.

2.2 Existing reverse proxy

Use this when nginx, Traefik, HAProxy, a load balancer, or another Caddy instance already terminates HTTPS. Josi publishes its web service on a configurable host port. Your proxy forwards HTTPS traffic to that port.

2.3 Local HTTP evaluation

Use this only on a trusted machine or trusted LAN for evaluation. Secure cookies must be disabled for plain HTTP. Never expose this mode to the public Internet.

3. Host requirements

3.1 Operating system and architecture

Use a 64-bit Linux host supported by Docker Engine. The application image is intended for linux/amd64 and linux/arm64.

Do not use a 32-bit operating system. Raspberry Pi installations require a 64-bit OS. Josi does not publish capacity claims yet; workload, connector use, and local inference change resource requirements substantially.

3.2 Required software

Install:

• Git
• Docker Engine
• Docker Compose v2, invoked as docker compose
• OpenSSL, or a readable /dev/urandom
• curl for host-side verification

Confirm each dependency:

git --version
docker version
docker compose version
openssl version
curl --version

docker-compose with a hyphen is the retired Compose v1 client. This manual uses Compose v2.

3.3 Docker access

Run Docker as root, or configure the installation account to access the Docker daemon. Membership in the docker group is effectively root-level access to the host. Treat it accordingly.

Verify access:

docker run --rm hello-world

3.4 Network requirements

For bundled Caddy:

• Create an A record pointing the chosen hostname to the server's public IPv4 address.
• Create an AAAA record only if IPv6 actually reaches the server.
• Forward TCP 80 and 443 through the router or firewall.
• Permit outbound DNS and HTTPS so Caddy can reach the ACME certificate authority and Josi can reach configured providers.

Check DNS from a machine outside the server's LAN:

dig +short A josi.example.com
dig +short AAAA josi.example.com

Replace josi.example.com everywhere in this manual with the real hostname.

If an incorrect AAAA record exists, some clients and certificate validation requests may use broken IPv6 even while IPv4 works. Remove the record or fix IPv6 routing.

4. Obtain the source

Choose a permanent directory. Do not run a long-lived installation from a Downloads folder.

sudo mkdir -p /opt/josi-ce
sudo chown "$(id -u):$(id -g)" /opt/josi-ce
git clone <REPOSITORY-URL> /opt/josi-ce
cd /opt/josi-ce

Until the repository is public, replace <REPOSITORY-URL> with the private clone URL available to the operator. Do not put access tokens directly in the command or shell history.

Confirm the checkout and inspect its state:

git remote -v
git status --short --branch
git log -1 --oneline

For a release, check out its signed or documented release tag instead of an arbitrary moving branch:

git fetch --tags
git checkout <RELEASE-TAG>

5. Read the configuration before starting

The repository includes these deployment files:

• docker-compose.yml: default stack and optional profiles
• docker-compose.noproxy.yml: publishes the web service for an existing proxy
• Caddyfile: bundled reverse proxy configuration
• .env.example: non-secret operator settings
• scripts/install.sh: generates the master key and database password

Validate the Compose model before creating anything:

docker compose config --quiet

This command expands configuration but does not start containers.

6. Configure .env

Copy the example and restrict its permissions:

cp .env.example .env
chmod 600 .env

The current .env contains no secrets, but restrictive permissions prevent a future operator-added value from becoming broadly readable.

Edit it with your preferred editor:

nano .env

6.1 Domain and application URL

Public HTTPS example:

JOSI_DOMAIN=josi.example.com
JOSI_APP_URL=https://josi.example.com
JOSI_COOKIE_SECURE=true
JOSI_HTTP_PORT=80
JOSI_HTTPS_PORT=443

JOSI_DOMAIN is the hostname Caddy serves. Do not include https://, a path, or a trailing slash.

JOSI_APP_URL is the browser-facing origin. Include the scheme. Do not add a trailing slash. OAuth redirect URLs and security checks depend on this value being the actual external URL.

JOSI_COOKIE_SECURE=true is required for HTTPS. A browser refuses to send a Secure cookie over plain HTTP.

Local HTTP evaluation example:

JOSI_DOMAIN=localhost
JOSI_APP_URL=http://localhost
JOSI_COOKIE_SECURE=false
JOSI_HTTP_PORT=80
JOSI_HTTPS_PORT=443

Do not use JOSI_COOKIE_SECURE=false on a public deployment.

6.2 Host ports

JOSI_HTTP_PORT maps the host's chosen port to Caddy port 80. JOSI_HTTPS_PORT maps the host's chosen port to Caddy port 443.

The normal public values are 80 and 443. Changing them means users must include the nonstandard port in the URL unless another device forwards standard ports.

Check for conflicts before starting:

sudo ss -lntp | grep -E ':(80|443)[[:space:]]' || true

6.3 Database names

Defaults:

POSTGRES_DB=josi
POSTGRES_USER=josi

These values are identifiers, not passwords. Changing either after the database volume has been initialized does not rename the existing database or user. Set them once before first start and leave them stable.

6.4 Application image

Defaults:

JOSI_IMAGE=josi-ce
JOSI_TAG=local

The current Compose file builds from the local checkout and tags the resulting image josi-ce:local. A future published release may provide a registry image and immutable version tag. Do not use a floating latest tag for a controlled deployment.

6.5 Optional-service limits

Defaults:

JOSI_OCR_CPUS=1.0
JOSI_OCR_MEMORY=512m
JOSI_CLAMAV_MEMORY=1500m

These are container ceilings. OCR and ClamAV do not start merely because the values exist. Their Compose profiles must also be selected.

ClamAV needs substantial memory while loading and updating signatures. Do not enable it on a constrained host without observing memory pressure.

7. Generate installation secrets

Run:

./scripts/install.sh

The script creates:

• secrets/master.key: encrypts stored provider, OAuth, and mail credentials
• secrets/db_password: authenticates the application to PostgreSQL

The directory is mode 0700; each file is mode 0600. Values are deliberately not printed.

Verify without changing anything:

./scripts/install.sh --check

The installer is idempotent: rerunning it leaves existing secret files alone. It never rotates the master key.

7.1 Master-key warning

The master key is not stored in PostgreSQL. That protects credentials if a database dump is stolen, but it creates an operational obligation:

Losing secrets/master.key makes encrypted credentials permanently unreadable. A database backup alone is insufficient.

Before continuing, copy the master key to encrypted storage on a different device. Example using removable media already mounted at /mnt/secure-backup:

install -m 600 secrets/master.key /mnt/secure-backup/josi-master.key

Do not email the key, paste it into chat, store it in Git, or include it in a normal unencrypted cloud folder. Record which installation it belongs to.

Check that Git ignores the generated directory:

git check-ignore -v secrets/master.key secrets/db_password

8. Build and start the default stack

Review the resolved configuration. This output should contain file paths but must not contain the secret values:

docker compose config

Build the application image:

docker compose build --pull

Start in detached mode:

docker compose up -d

Watch startup:

docker compose ps
docker compose logs -f --tail=200

Press Ctrl+C to stop following logs. This does not stop the containers.

Expected state:

• db, web, worker, and caddy are running.
• migrate exited with code 0 after applying migrations.
• ocr and clamav do not exist unless their profiles were enabled.

Inspect a failed service without restarting the whole stack:

docker compose logs --tail=300 <SERVICE>
docker compose ps -a

Replace <SERVICE> with db, migrate, web, worker, or caddy.

9. Verify the installation

9.1 Container health

docker compose ps

Do not equate "running" with "ready." The health and readiness endpoints test different layers.

9.2 Liveness

For public HTTPS:

curl -fsS https://josi.example.com/health

For localhost evaluation:

curl -fsS http://localhost/health

Liveness means the API process answers.

9.3 Readiness

curl -fsS https://josi.example.com/ready

Readiness additionally checks the database, migrations, and master-key availability. A live but unready service should not receive normal traffic.

9.4 TLS and redirects

curl -I http://josi.example.com
curl -I https://josi.example.com
openssl s_client -connect josi.example.com:443 -servername josi.example.com </dev/null

If certificate issuance fails, check DNS, inbound ports, Caddy logs, router port forwarding, firewall policy, and incorrect IPv6 records.

9.5 Optional services remain absent

docker compose ps --all
docker ps --format '{{.Names}}' | grep -E '(ocr|clamav)' && echo unexpected || echo absent

10. Complete the setup wizard

Open JOSI_APP_URL in a browser. A fresh installation exposes the setup wizard and refuses normal application routes until setup completes.

The wizard covers:

1. Host checks
2. Super-admin account
3. Domain and HTTPS review
4. LLM provider
5. System and Josi mail profiles
6. Optional Google and Microsoft connector clients
7. Security and privacy choices
8. Explicit telemetry choice
9. Review and completion

Setup is single-use. After completion, setup routes return 404 and cannot be used to create another super administrator.

Record recovery information in the organization's password manager. Do not put provider keys, OAuth secrets, SMTP passwords, or recovery material in this repository.

11. Enable optional OCR and ClamAV profiles

Profiles may be combined.

OCR only:

docker compose --profile ocr up -d

ClamAV only:

docker compose --profile clamav up -d

Both:

docker compose --profile ocr --profile clamav up -d

Verify:

docker compose --profile ocr --profile clamav ps
docker compose logs --tail=200 ocr clamav

ClamAV's first signature load can take several minutes. Its healthcheck allows a five-minute start period.

To stop and remove an optional service while leaving the core running:

docker compose stop ocr
docker compose rm -f ocr

Use clamav in place of ocr for the malware scanner. Removing the ClamAV container does not remove the named signature volume unless you deliberately remove volumes.

Current implementation limitation: Phase 9 does not yet wire the real OCR, ClamAV, parser, filesystem-watcher, or cloud-sync machinery into a complete document pipeline. Enabling a container does not make the unfinished feature production-ready.

12. Use an existing reverse proxy

Create .env with the real public URL and a local published port:

JOSI_DOMAIN=josi.example.com
JOSI_APP_URL=https://josi.example.com
JOSI_COOKIE_SECURE=true
JOSI_WEB_PORT=8080

Start with the override and scale bundled Caddy to zero:

docker compose \
  -f docker-compose.yml \
  -f docker-compose.noproxy.yml \
  up -d --scale caddy=0

Josi is then available to the host proxy at http://127.0.0.1:8080 if Docker binds to loopback. The current override publishes on all host interfaces. If the machine is not protected by a firewall, tighten the port mapping in a local override:

services:
  web:
    ports:
      - "127.0.0.1:${JOSI_WEB_PORT:-8080}:8080"

Save that as docker-compose.local.yml and include it last:

docker compose \
  -f docker-compose.yml \
  -f docker-compose.noproxy.yml \
  -f docker-compose.local.yml \
  up -d --scale caddy=0

The external proxy must:

• Terminate HTTPS with a valid certificate.
• Preserve the original Host header.
• Forward X-Forwarded-For.
• Forward X-Forwarded-Proto: https.
• Support normal long-lived HTTP responses used by the application.
• Apply sensible request-size and timeout limits without truncating supported application traffic.

Minimal nginx location:

location / {
    proxy_pass http://127.0.0.1:8080;
    proxy_http_version 1.1;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;
}

After proxy changes, verify /health, /ready, login, logout, and a browser refresh on an authenticated route.

13. Firewall guidance

Bundled Caddy normally needs only:

• TCP 22 from trusted administration addresses, if SSH is used
• TCP 80 from the Internet
• TCP 443 from the Internet

Do not expose PostgreSQL. The Compose file publishes no database port.

Example UFW policy, only after confirming SSH access and adjusting the SSH rule for the actual environment:

sudo ufw allow OpenSSH
sudo ufw allow 80/tcp
sudo ufw allow 443/tcp
sudo ufw enable
sudo ufw status verbose

Firewall changes can lock you out. Keep an existing SSH session open and test a second session before closing the first.

14. Normal operations

Show status:

docker compose ps

Follow all logs:

docker compose logs -f --tail=200

Follow one service:

docker compose logs -f --tail=200 web

Restart one service:

docker compose restart web

Stop without deleting containers or volumes:

docker compose stop

Start stopped containers:

docker compose start

Recreate containers from the current configuration:

docker compose up -d

14.1 Commands that are intentionally not routine

docker compose down removes containers and networks but preserves named volumes unless --volumes is supplied.

Never run docker compose down --volumes as an ordinary troubleshooting step. It deletes the PostgreSQL data volume and other named volumes.

Do not delete secrets/master.key. Do not regenerate it to fix a startup problem. A replacement key cannot decrypt existing credentials.

15. Backup and restore status

Josi's required encrypted, restorable backup workflow belongs to Phase 10 and is not yet implemented. Therefore this preview cannot honestly provide the promised supported backup and restore commands.

Before storing important data, wait for Phase 10 and its destructive backup-wipe-restore acceptance test to pass. A manual PostgreSQL dump is not a substitute for that complete workflow because it may omit application files, history copies, configuration, and the separately held master key.

At minimum, any future complete backup set must preserve:

• PostgreSQL data
• The exact secrets/master.key
• Application configuration
• Uploads and recovery/history data when those features exist
• A record of the Josi release being restored

The master key must be protected separately from the database backup. Restore must fail safely when the wrong key is supplied.

16. Upgrade and rollback status

The required one-click update, pre-update backup, health check, and automatic rollback belong to Phase 10 and are not yet implemented.

Do not improvise an in-place production upgrade of this preview. Pulling new source and running docker compose up -d --build can apply irreversible database migrations. Without a verified pre-update backup and rollback path, that is not an acceptable production procedure.

A supported release procedure will be documented here only after the automated backup/restore and failed-update rollback tests exist and pass.

17. Troubleshooting

17.1 Compose cannot read a secret file

Symptoms include secrets/master.key not found or secrets/db_password not found.

./scripts/install.sh --check
ls -ld secrets
ls -l secrets/master.key secrets/db_password

Run commands from the repository root. Do not solve permission errors by making the secrets world-readable.

17.2 Database is unhealthy

docker compose ps db
docker compose logs --tail=300 db
docker inspect --format '{{json .State.Health}}' josi-ce-db-1

Container names can vary with the Compose project name. Use docker compose ps -q db when scripting:

docker inspect --format '{{json .State.Health}}' "$(docker compose ps -q db)"

Common causes are disk exhaustion, filesystem permission problems, corrupt storage, and changing database identifiers after initialization.

17.3 Migrator exited nonzero

docker compose ps -a migrate
docker compose logs --tail=500 migrate

Do not repeatedly delete the database volume. Preserve the evidence, identify the failing migration, and use the release's documented recovery path.

17.4 Web is running but /ready fails

docker compose logs --tail=300 web
curl -i http://127.0.0.1/ready
./scripts/install.sh --check

Readiness distinguishes database, migrations, and master-key failures. Fix the reported dependency instead of masking the check.

17.5 Login works locally but fails through a proxy

Confirm:

• JOSI_APP_URL exactly matches the browser's HTTPS origin.
• JOSI_COOKIE_SECURE=true for HTTPS.
• The proxy sends X-Forwarded-Proto: https.
• The browser is not being redirected between different hostnames.
• System time is correct.

For plain HTTP evaluation only, set JOSI_COOKIE_SECURE=false, recreate the web container, and clear cookies for the host.

17.6 Caddy restarts or cannot issue a certificate

docker compose ps caddy
docker compose logs --tail=500 caddy
dig +short A josi.example.com
dig +short AAAA josi.example.com

Check that ports 80 and 443 reach this server, that another service is not already bound to them, and that DNS does not contain a stale address.

JOSI_ACME_EMAIL in .env is currently informational. The supplied Caddyfile does not interpolate it because an empty email directive makes Caddy fail to parse. Certificate issuance works without an ACME contact address.

17.7 Port already in use

sudo ss -lntp | grep -E ':(80|443|8080)[[:space:]]'
docker ps --format 'table {{.Names}}\t{{.Ports}}'

Stop the conflicting service, choose different host ports, or use the existing reverse-proxy deployment shape.

17.8 Docker build fails

docker compose build --pull --no-cache
docker system df
df -h
df -i

Capture the first real compiler or package error, not only the final nonzero exit line. Do not run broad Docker prune commands on a shared host without reviewing what they will delete.

17.9 Host is out of disk space

Inspect before removing anything:

df -h
docker system df -v
docker volume ls
docker image ls

Do not delete a volume merely because its name looks old. Confirm ownership and take a restorable backup first.

17.10 Host architecture mismatch

uname -m
docker info --format '{{.Architecture}}'
docker image inspect "${JOSI_IMAGE:-josi-ce}:${JOSI_TAG:-local}" --format '{{.Architecture}}'

Use a 64-bit amd64 or arm64 OS and matching image.

17.11 ClamAV remains unhealthy

docker compose --profile clamav ps clamav
docker compose --profile clamav logs --tail=500 clamav
docker stats --no-stream

Allow time for initial signature loading and verify the host has enough memory. An out-of-memory kill appears in container state and host kernel logs.

18. Security checklist

Before considering an installation reachable by other people, confirm:

• The checkout is an intended release, not an arbitrary dirty branch.
• scripts/scan-secrets.sh passes.
• scripts/install.sh --check passes.
• The master key has an encrypted off-host copy.
• .env contains the correct public origin.
• HTTPS works with a valid certificate.
• Secure cookies remain enabled for HTTPS.
• PostgreSQL is not published to the host or Internet.
• Host security updates are enabled and current.
• SSH uses strong authentication and limited network exposure.
• Optional OCR and ClamAV services are enabled only when supported and resourced.
• Provider, OAuth, and SMTP credentials belong to the operator.
• External LLM processing is disclosed to users.
• Telemetry was explicitly chosen rather than assumed.
• /health and /ready are monitored.
• Phase 10 backup and restore acceptance has passed before important data is entrusted to the system.
• Phase 11 threat-model and release gates have passed before public launch.

19. Collecting useful support information

The redacted diagnostics bundle is a Phase 10 feature and does not yet exist. Until it does, inspect logs locally and redact them before sharing. Never send:

• secrets/master.key
• secrets/db_password
• Provider API keys
• OAuth client secrets or access/refresh tokens
• SMTP passwords
• Message, document, contact, calendar, or prompt content

Safe first-line metadata usually includes the Josi commit or release, host OS, CPU architecture, Docker versions, Compose service state, the failing endpoint, and the exact error after secrets and user content are removed.

git rev-parse HEAD
uname -a
docker version
docker compose version
docker compose ps -a

20. Uninstallation

There is no supported uninstall-and-preserve-data wizard yet.

Stopping the installation is reversible:

docker compose stop

Removing containers and networks while retaining named volumes:

docker compose down

Deleting named volumes or the installation directory destroys data. Before any permanent removal, create and verify a complete backup when Phase 10 tooling is available, and separately preserve the master key. This manual deliberately does not provide a one-line destructive wipe command.
